Porta
4
Pulsante
Reset, WPS
LED
• 1 * Signal LED
• 1 * WPS LED
• 1 * Power LED
Fonte d'alimentazione
5V 1A, built-in
Tipo di spinotto
EU、UK、US、AU、AR
Consumo energetico
No-load: 1.6W, Full-load: 3.8W
Standard e Protocollo
IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n on 2.4 GHz
Efficienza
• 802.11b: 11 Mbps
• 802.11g: 54 Mbps
• 802.11n: 300 Mbps
Banda di frequenza
11n: 2.412-2.484 GHz
Potenza di trasmissione
< 20 dBm (EIRP)
Antenna
2 * External 3dBi omni-directional antenna (non-detachable)
Canale
11n: 20/40MHz by default
Modalità di funzionamento
• Repeater Mode
• AP Mode
Wireless security protocol
• Encryption mode: Mix WPA-PSK/WPA2-PSK
• WPA algorithm: TKIP&AES
Server DHCP
Support
Elementi del sistema
Firmware upgrade, Restore factory settings, Login password, and Reboot
Dimensioni
80mm * 58mm * 48mm
Temperatura
• Operating temperature:0ºC~40ºC
• Storage temperature:-40ºC~70℃
Umidità
• Operating humidity:(10 – 90)% RH, non-condensing
• Storage temperature:5%~90%RH, non-condensing
Certificazioni
CE、FCC、RoHs
